Gebildet DC Voltage Converter Regulator, DC 12V Step-Up to 24V 10A 240W, Buck Transformer Waterproof

Package Contents: 1 x DC 12-24V 10A Voltage Converter Application: 12V DC as input power to 24V DC appliances as output load. Specifications: Input Rated Voltage: 12V DC Input Voltage Range: 11-16V DC Output voltage: DC24V 20A Output Rated Power: 240W Efficiency: 97% (half load); 95% (full load) Ripple: 100mVp Line Regulation: ±0.2% Load Regulation: ±0.2% Voltage Accuracy: ±1.5% Enclosures: IP68 Case Operating Temperature: -40~85°C Weight: 260g Features: 1. 100% full power and stable current output, non-isolated module. 2. Industry grade DC12V to DC24V step-down converter, efficiency up to 95%. 3. Die-cast aluminum shell, epoxy potting, cooling by free air convection; Waterproof level IP68 and anti-shock protection. 4. Protections: Over-current, Over-voltage, Over-temperature, Over-load and Short-circuit, auto-recovery when device is back to normal operating. Note: * Never connect to solar panel, PWM/MPPT charge controller, inverter or wind turbine. * Never charge. Keep good air convection. * Never reverse the polarity. * Use the enough big cable to avoid the voltage drop.

• Input voltage range: DC 11-16V; Output voltage: DC 24V(non-adjustable); Output current: 10A; Output power 240W. Waterproof Level upgrade: IP68,moisture-proof & anti-shock protection
• Sturdy and Safe materials: die-cast aluminum shell and high quality design, maximum transfer efficiency of 95%.
• More safer: built in smart chip, full protection against over/under voltage input, over-current, overload, overhead, over-temperature and short circuit
• Better Heat Dissipation:Upgraded fin type heat sink with a thick aluminum plate inside fixture to help to dissipate heat more efficiently long life.
• 95% conversion efficiency: Synchronization rectification technology-multiple intelligent protection function with high conversion efficiency and stability.
